Boeing 737-600 - Page 2027

F
W
D
B
1
1
C
1
SPEED BRAKE
CONTROL LEVER
CRANK
CRANK
[8] BOLT
THRUST
LEVERS
[8] BOLT
ENGINE START
LEVERS
[11] LEFT STABILIZER
TRIM WHEEL
THRUST
REVERSER
LEVERS
[7] RIGHT STABILIZER
TRIM WHEEL
[9] SCREW
(4 LOCATIONS)
[10] STABILIZER
TRIM SWITCH
PANEL
[6] STABILIZER
TRIM HORN
CUTOUT SWITCH
KNOB
SPACER
SPACER
SPACER NOT INSTALLED WITH
COUNTERSUNK HEAD BOLT
G02561 S0006583042_V3
Control Stand Installation
Figure 401/76-11-01-990-801-F00 (Sheet 2 of 3)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-01
Page 410
D633A101-ILF Oct 15/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
