Boeing 737-600 - Page 2157

C
F
W
D
[23] TOP JAMNUT
[25] BOTTOM JAMNUT
[28] NUT
(2 LOCATIONS)
[29] WASHER
(2 LOCATIONS)
[26] BOLT
[27] WASHER
[24] SPINNING ROD
[20] ROD
ASSEMBLY
LEFT INTERLOCK SOLENOID
(RIGHT INTERLOCK SOLENOID IS OPPOSITE)
[30] SPACER
INTERLOCK SOLENOID
INTERLOCK
LATCH ASSEMBLY
AUTOTHROTTLE
ASSEMBLY
[21] NUT
[22] WASHER
0.0682 ±0.030 INCH
(1.7323 ±0.762 mm)
G57466 S0006583110_V2
Reverse Thrust Interlock Solenoid Installation
Figure 402/76-11-06-990-802-F00 (Sheet 3 of 3)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-06
Page 411
D633A101-ILF Jun 15/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
