D
FWD
C
E
E
F
W
D
D
E
[1] COVER
ASSEMBLY
EXTERNAL POWER
RECEPTACLE
NUT
(TORQUE 20-22
POUND-INCHES)
(2 LOCATIONS)
NUT
(TORQUE 120-125
POUND-INCHES)
(4 LOCATIONS)
[3] WASHER
(4 LOCATIONS)
[2] NUT
(4 LOCATIONS)
[4] WASHER
(4 LOCATIONS)
NOSE LANDING GEAR WHEEL WELL
LOCKWASHER
FLAT WASHER
TERMINAL LUG
NUT
RECEPTACLE STUD BUILDUP
(EXAMPLE)
2103460 S0000447875_V3
External Power Receptacle Inspection
Figure 603/24-41-11-990-806 (Sheet 3 of 4)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-41-11
Page 614
D633A101-ILF Oct 15/2015
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 593-599, 601-603, 606, 607, 610-615, 620,
625-627, 691-699, 833-835, 838
