ILF 496-500, 560-564, 567-569, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615, 620, 625-627, 671,
672, 691-699, 833-835, 838, 948, 968-973, 980-999 (Continued)
(Continued)
Power Distribution Panel Number 2, P92
Row Col Number Name
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 402, 405, 406,
409, 410, 412, 416, 424, 425, 427-429, 451, 452, 491-495, 501-504, 507-510, 512-516, 518-520,
523-528, 530-533, 535-537, 541, 542, 552-557, 559, 571-577, 686, 703, 707-710, 803-813, 821,
822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863, 871-874, 947
D 6 C00846 FUEL BOOST PUMP CTR TANK RIGHT
ILF ALL
F 3 C00881 ELEC HYD PUMP SYS A
CAUTION
DO NOT OPERATE THE BOOST PUMPS WITH THE FUEL TANKS
EMPTY. DAMAGE TO THE BOOST PUMPS CAN OCCUR.
(b) Set these switches on the Fuel System Panel (P5) to the ON position:
1) 1 AFT FUEL PUMP
2) 1 FWD FUEL PUMP
3) 2 AFT FUEL PUMP
4) 2 FWD FUEL PUMP
5) L CTR FUEL PUMP
6) R CTR FUEL PUMP.
WARNING
KEEP PERSONNEL AND EQUIPMENT AWAY FROM THE FLIGHT
CONTROL SURFACES, THE THRUST REVERSERS, AND THE LANDING
GEAR. THESE COMPONENTS CAN MOVE SUDDENLY WHEN YOU
SUPPLY HYDRAULIC POWER. THIS CAN CAUSE INJURIES TO
PERSONNEL AND DAMAGE TO EQUIPMENT.
(c) Set these switches on the Hydraulic Pump Panel (P5) to the ON position:
1) A ELEC 2 HYD PUMP
2) B ELEC 1 HYD PUMP.
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 402, 405, 406, 409,
410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510, 512-516, 518-520, 523-528, 530-533,
535-537, 541, 542, 552-557, 559-564, 567-569, 571-577, 581, 583, 585, 588-590, 592-599, 601-603,
606, 610-615, 620, 671, 672, 686, 691-699, 703, 707-710, 803-813, 821, 822, 831-833, 836, 837, 841,
842, 851, 852, 854-858, 861-863, 871-874, 947, 948, 968-973, 980-999
(d) Set these switches on the Exterior Light Control Panel (P5) to the ON position:
1) L RETRACTABLE LANDING
2) R RETRACTABLE LANDING
3) L FIXED LANDING
4) R FIXED LANDING.
ILF 607, 625-627, 834, 835, 838
(e) Set these switches on the Exterior Light Control Panel (P5) to the ON position:
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-11-00
Page 504
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
