Boeing 737-600 - Page 486

A
B
A
F
W
D
B
F
W
D
TRANSFORMER
FLIGHT COMPARTMENT
(VIEW IN THE AFT DIRECTION)
[1] TRANSFORMER
[5] WASHER
(4 LOCATIONS)
[6] BOLT
(4 LOCATIONS)
[3] WASHER (QTY 2)
(3 LOCATIONS)
[4] NUT
(3 LOCATIONS)
[2] WIRE TERMINAL
(3 LOCATIONS)
TRANSFORMER
BRACKET
2131322 S0000461566_V3
28-Volt AC Transformer Installation
Figure 401/24-52-01-990-801
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-52-01
Page 403
D633A101-ILF Oct 15/2015
