Boeing 737-600 - Page 94

A
F
W
D
B
A
F
W
D
B
[4] WASHER
(8 LOCATIONS)
[3] BOLT
(8 LOCATIONS)
OIL-OUT LINE
OIL-IN LINE
ENGINE
FAN CASE
OIL-IN
UNION
[2] GASKET
[1] IDG AIR/OIL
COOLER
OIL-OUT
UNION
NOTE:
CFMI WIRE HARNESSES ARE NOT SHOWN.
F28303 S0006566145_V4
Integrated Drive Generator (IDG) Air/Oil Cooler Installation
Figure 401/24-11-21-990-801
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-11-21
Page 405
D633A101-ILF Oct 15/2015
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
