Chapter 26 Configuration of RMON DGS-3610 Series Configuration Guide

26-6

Pkts : 726

BroadcastPkts : 502

MulticastPkts : 189

CRCAlignErrors : 0

UndersizePkts : 0

OversizePkts : 0

Fragments : 0

Jabbers : 0

Collisions : 0

Utilization : 0

26.3.4.4 show rmon statistics

DGS-3610# show rmon statistics

Statistics : 1

Data source : Gi1/1

DropEvents : 0

Octets : 1884085

Pkts : 3096

BroadcastPkts : 161

MulticastPkts : 97

CRCAlignErrors : 0

UndersizePkts : 0

OversizePkts : 1200

Fragments : 0

Jabbers : 0

Collisions : 0

Pkts64Octets : 128

Pkts65to127Octets : 336

Pkts128to255Octets : 229

Pkts256to511Octets : 3

Pkts512to1023Octets : 0

Pkts1024to1518Octets : 1200

Owner : zhangsan
