DGS-3610 Series Configuration Guide Chapter 37 Configuration of 802.1X
37-11
following example sets the Server IP to 192.168.4.12, authentication UDP port to 600, and
the key to agreed password:
DGS-3610# configure terminal
DGS-3610(config)# radius-server host 192.168.4.12
DGS-3610(config)# radius-server host 192.168.4.12 auth-port 600
DGS-3610(config)# radius-server key MsdadShaAdasdj878dajL6g6ga
DGS-3610(config)# end
 The officially agreed authentication UDP port is 1812.
 The officially agreed accounting UDP port is 1813.
 No less than 16 characters are recommended for the agreed password between the
device and the Radius Server.
 The port of the device to connect the Radius Server shall be configured as uncontrolled
port.
37.2.4 Setting the 802.1X Authentication
Switch
When the 802.1X authentication is enabled, the switch will impose authentication over the
host connected to the controlled port, and the hosts that fail the authentication are not
allowed to access the network.
In the privileged mode, you can enable the 1x authentication through the following steps:
Command
Function
configure terminal
Enter the global configuration mode.
aaa new-model
Turn on the AAA switch.
radius-server host ip-address [auth-port
port ]
[acct-port port]
Configure the RADIUS server
Radius-server key string
Configure RADIUS Key.
aaa authentication dot1x auth group
radius
Configure the dot1x authentication method list
dot1x authentication auth
dot1x applies authentication method list
end
Return to the privileged mode.
write
Save the configuration.
show running-config
Show the configuration.
The following example enables 802.1X authentication:
DGS-3610# configure terminal
DGS-3610(config)# aaa new-model
DGS-3610(config)# radius-server host 192.168.217.64
DGS-3610(config)# radius-server key starnet
