D-Link xStack DGS-3610 Series User Manual

Chapter 10 Protocol VLAN Configuration DGS-3610 Series Configuration Guide
10-4
Command
Description
no protocol-vlan profile id
Clear certain profile on this port
end
Exit the interface mode
The following example applies profile 1 and profile 2 to the GE port 1 of Slot 3. The VLAN is
classfied to VLAN 101 and 102:
DGS-3610# configure terminal
DGS-3610(config)# interface gi 3/1
DGS-3610(config-if)# protocol-vlan profile 1 vlan 101
DGS-3610(config-if)# protocol-vlan profile 2 vlan 102
DGS-3610(config-if)# end
DGS-3610# show protocol-vlan profile
profile frame-type ether-type Interfaces|vid
------- --------- ---------- --------------
1 ETHERII EHTER_AARP gi3/1|101
2 SNAP ETHER_APPLETALK gi3/1|102
Note
1. Any profiles can be applied to each interface.
2. Different VIDs can be specified for the same profile on different
interfaces.
3. According to the various series of products, the quantity of vids
specified is different , DGS-3610 series devices can specify 4094
VLANs.
10.3 Showing Protocol VLAN
You can show the contents of Protocol VLAN using the following commands:
Command
Description
show protocol-vlan
Show the contents of Protocol VLAN
DGS-3610# show protocol-vlan
ip mask vlan
------------- ------------- ----
192.168.100.3 255.255.255.0 100
profile frame-type ether-type Interfaces|vid
------- --------- ---------- --------------
1 ETHERII EHTER_AARP gi3/1|101
2 SNAP ETHER_APPLETALK gi3/1|1
