DGS-3610 Series Configuration Guide Chapter 45 QOS Configuration
45-7
Default COS: trust dscp
Default COS: 6
DGS-3610#
45.2.4 Configuring Class Maps
You may create and configure Class Maps through the following steps:
Command
Description
configure terminal
Enter the configuration mode
ip access-list extended {id | name}
…
ip access-list standard {id | name}
…
mac access-list extended {id | name}
…
expert access-list extended {id |
name}
…
ipv6 access-list extended name
…
access-list id […]
Create ACL
Please refer to the chapter of ACL
[no] class-map class-map-name
Create and enter into the class map configuration mode,
where class-map-name is the name of the class map to be
created.
The no option will delete an existing class map
[no] match access-group {acl-num |
acl-name }
Set the matching ACL, where acl-name is the name of the
created ACL,
acl-num is the ID of the created ACL; the no option delete
that match.
For example, the following steps creates a class-map named class1, which is associated
with an ACL:acl_1. This class-map will classify all TCP packets with port 80.
DGS-3610(config)# ip access-list extended acl_1
DGS-3610(config-ext-nacl)# permit tcp any any eq 80
DGS-3610(config-ext-nacl)# exit
DGS-3610(config)# class-map class1
DGS-3610(config-cmap)# match access-group acl_1
DGS-3610(config-cmap)# end
45.2.5 Configuring Policy Maps
You may create and configure Policy Maps through the following steps:
