DGS-3610 Series Configuration Guide Chapter 45 QOS Configuration
45-13
DGS-3610# configure terminal
DGS-3610(config)# mls qos map dscp-cos 0 32 56 to 6
DGS-3610(config)# show mls qos maps dscp-cos
dscp cos dscp cos dscp cos dscp cos
---- --- ---- --- ---- --- ---- ---
0 6 1 0 2 0 3 0
4 0 5 0 6 0 7 0
8 1 9 1 10 1 11 1
12 1 13 1 14 1 15 1
16 2 17 2 18 2 19 2
20 2 21 2 22 2 23 2
24 3 25 3 26 3 27 3
28 3 29 3 30 3 31 3
32 6 33 4 34 4 35 4
36 4 37 4 38 4 39 4
40 5 41 5 42 5 43 5
44 5 45 5 46 5 47 5
48 6 49 6 50 6 51 6
52 6 53 6 54 6 55 6
56 6 57 7 58 7 59 7
60 7 61 7 62 7 63 7
45.2.12 Configuring Port Rate Limit
You may follow these steps to limit the port rate:
Command
Description
configure terminal
Enter the configuration mode
interface interface
Enter the interface configuration mode.
rate-limit output
bps burst-size
Port rate limit, where input is the input rate limit, output is
the output rate limit, bps is the bandwidth limit per second
(kbps),
and burst-size is the burst bandwidth limit (Kbyte)
no rate-limit
Cancel port rate limiting
DGS-3610# configure terminal
DGS-3610(config)# interface gigabitEthernet 0/4
DGS-3610(config-if)# rate-limit input 100 100
DGS-3610(config-if)# end
DGS-3610#
45.2.13 Configuring IPpre to DSCP Map
IPpre-to-Dscp is used to map the IPpre values of a packet to internal DSCP values. The
default settings of IPpre-to-DSCP Map are provided in the default QoS configuration section.
you may follow these steps to configure IPpre-to-Dscp Map:
