Chapter 34 OSPFv3 Configuration DGS-3610 Series Configuration Guide

34-14

Command

Function

show ipv6 ospf neighbor[process-id]

[detail] [neighbor-id | interface-type

interface-number [neighbor-id]]

Show the neighbor information of the OSPFv3

process.

show ipv6 ospf [process-id] route

Show the OSPFv3 route information.

show ipv6 ospf [process-id] topology

[area area-id]

Show each area topology of the OSPFv3.

show ipv6 ospf [process-id]

virtual-links

Show the virtual link information of the OSPFv3

process.
