set lldp port tx-tlv
SecureStack C2 Configuration Guide 4-27
Syntax
set lldp port tx-tlv {[all] | [port-desc] [sys-name] [sys-desc] [sys-cap] [mgmt-
addr] [vlan-id] [stp] [lacp] [gvrp] [mac-phy] [poe] [link-aggr] [max-frame] [med-
cap] [med-loc] [med-poe]} port-string
Parameters
all AddsalloptionalTLVstotransmittedLLDPDUs.
port‐desc PortDescriptionoptionalbasicLLDPTLV.ValuesentisifDescrobject
definedinRFC2863.
sys‐name SystemNameoptionalbasicLLDPTLV.Valuesentisthe
administrativelyassignednameforthesystem.
sys‐desc SystemDescriptionoptionalbasicLLDPTLV. Valuesentis
sysDescr
objectdefinedinRFC3418.
sys‐cap SystemCapabilitiesoptionalbasicLLDPTLV. Foranetwork
connectivitydevice,valuesentcanbe bridge and/orrouter.
mgmt‐addr ManagementAddressoptionalbasicLLDPTLV.ValuesentisIPv4
addressofhostinterface.
vlan‐id PortVLANIDIEEE802.1ExtensionsTLV.Valuesentis
portVLAN
ID(PVID).
stp SpanningTreeinformationdefinedbyProtocolIdentityIEEE802.1
ExtensionsTLV.IfSTPisenabledontheport,valuesentincludes
versionof protocolbeingused.
lacp LACPinformationdefinedbyProtocolIdentityIEEE802.1
ExtensionsTLV.IfLACPisenabledontheport,valuesentincludes
versionofprotocolbeingused.
gvrp GVRPinformationdefinedbyProtocolIdentityIEEE802.1
ExtensionsTLV.IfLACPisenabledontheport,valuesentincludes
versionofprotocolbeingused.
mac‐phy MAC‐PHYConfiguration/StatusIEEE802.3ExtensionsTLV.Value
sentincludestheoperationalMAUtype,duplex,andspeedofthe
port.
poe PowerviaMDIIEEE802.3ExtensionsTLV.Valuessentinclude
whetherpairselectioncanbecontrolledonport,andthepowerclass
suppliedbytheport.OnlyvalidforPoE‐enabledports.
link‐aggr LinkAggregationIEEE802.3ExtensionsTLV.Valuessentindicate
whetherthelinkassociatedwiththisportcan
beaggregated,
whetheritiscurrentlyaggregated,andifaggregated,theaggregated
portidentifier.
max‐frame MaximumFrameSizeIEEE802.3ExtensionsTLV.Valuesent
indicatesmaximumframesizeoftheport’sMACandPHY.
med‐cap LLDP‐MEDCapabi litiesTLV. Valuesentindicatesthecapabilities
(whetherthedevicesupportslocationinformation,extendedpower

viaMDI)andDeviceType(networkconnectivitydevice)ofthe
sendingdevice.
med‐loc LLDP‐MEDLocationIdentificationTLV.ValuesentistheECSELIN
valueconfiguredontheport.Seethesetlldpportlocation‐info
commandformoreinformation.
