show lacp
5-36 Port Configuration
Parameters
Defaults
Ifport‐stringisnotspecified,linkaggregationinformationforallLAGswillbedisplayed.
Mode
Switchcommand,read‐only.
Usage
EachSecureStackC2moduleprovides6virtuallinkaggregatorports,whicharedesignatedinthe
CLIaslag.0.1throughlag.0.6.Onceunderlyingphysicalports(thatis,
ge.x.x)areassociatedwith
anaggregatorport,theresultingaggregationwillberepresentedasoneLinkAggregationGroup
(LAG)withalag.x.xportdesignation.
Example
Thisexampleshowshowtodisplaylacpinformationforlag.0.1.Thefollowingtabledescribesthe
outputfields.
C2(su)->show lacp lag.0.1
Global Link Aggregation state: enabled
Single Port LAGs: disabled
Aggregator: lag.0.1
Actor Partner
System Identifier: 00:01:F4:5F:1E:20 00:11:88:11:74:F9
System Priority: 32768 32768
Admin Key: 32768
Oper Key: 32768 0
Attached Ports: ge.1.1
ge.1.3
Table 5‐6providesanexplanationofthecommandoutput.
port‐string (Optional)DisplaysLACPinformationforspecificLAGport(s).Valid
portdesignationsarelag.0.1‐6.
Table 5-6 show lacp Output Details
Output What It Displays...
Global Link
Aggregation state
Shows if LACP is enabled or disabled on the switch.
Single Port LAGs Displays if the single port LAG feature has been enabled on the switch. See “set lacp
singleportlag” on page 5-40 for more about single port LAG.
Aggregator LAG port designation. Each SecureStack C2 module provides 6 virtual link
aggregator ports, which are designated in the CLI as lag.0.1 through lag.0.6. Once
underlying physical ports (for example, ge.x.x) are associated with an aggregator
port, the resulting Link Aggregation Group (LAG) is represented with a lag.x.x port
designation.
Actor Local device participating in LACP negotiation.
Partner Remote device participating in LACP negotiation.
System Identifier MAC addresses for actor and partner.
