Port Configuration Summary
5-2 Port Configuration
•FourSFPslotsthatprovidetheoptionofinstallingSmallFormPluggable(SFP)Mini‐GBICs
for1000BASE‐Tcompliantcopperconnectionsor1000BASE‐SX\LX\ELXfiber‐optic
connections.
C2G134-24P Switch Ports
TheC2G134‐24Pstackabledevicesprovidethefollowingtypesofswitchportconnections:
•Twenty‐four10/100/1000Mbps1000BASE‐TFastEthernetcopperportsconnectedthrough
fourRJ21connectors(sixportsperRJ21).
•FourSFPslotsthatprovidetheoptionofinstallingSmallFormPluggable(SFP)Mini‐GBICs
for1000BASE‐Tcompliantcopper
connectionsor1000BASE‐SX\LX\ELXfiber‐optic
connections.
C2K122-24 Switch Ports
TheC2K122‐24stackabledevicesprovidethefollowingtypesofswitchportconnections:
•Twenty‐fourRJ4510/100/1000Mbps1000BASE‐TFastEthernetcopperports
•TwoXFPslotsthatprovidetheoptionofinstallingXFPMSA‐compliantmodulesfor10‐
Gigabit,10GBASE‐L/‐LR/‐ERfiber‐opticconnections.
C2G170-24 Switch Ports
TheC2G170‐24stackabledevicesprovidethefollowingtypesofswitchportconnections:
•Twenty‐fourSFPslotsthatprovidetheoptionofinstallingSmallFormPluggable(SFP)Mini‐
GBICsfor1000BASE‐Tcompliantcopperconnectionsor1000BASE‐SX\LX\ELX.
Port String Syntax Used in the CLI
Commandsrequiringaport‐stringparameterusethefollowingsyntaxtodesignateporttype,slot
location,andportnumber:
porttype.unitnumber.portnumber
Whereporttypecanbe:
fefor100‐MbpsEthernet
gefor1‐GbpsEthernet
tgfor10‐GbpsEthernet
hostforthehostport
vlanforvlaninterfaces
lagfor
IEEE802.3linkaggregationports
Unitnumbercanbe:
1‐8forswitchunitsinaSecureStackC2stack
Important Notice About C2G1x4-xx 10/100/100 and SFP Mini-GBIC Ports
SFP Mini-GBIC uplink ports are used in an either / or configuration with the C2 front panel RJ45 10/100/1000
Mbps 1000BASE-T Fast Ethernet copper ports. If all Mini-GBIC ports are used, four of the RJ45 ports will be
disabled. The maximum number of active ports can be 24 on the C2G124-24, and 48 on the C2G124-48 and
C2G124-48P, in any combination of RJ45s and Mini-GBICs.
