Enterasys SecureStack C2

set rmon capture
13-20 RMON Configuration
Parameters
Defaults
Ifnooptionsarespecified,allbuffercontrolentriesandassociatedcapturedpacketswillbe
displayed.
Mode
Switchcommand,read‐only.
Example
ThisexampleshowshowtodisplayRMONcaptureentriesandassociatedbufferentries:
C2(rw)->show rmon capture
Buf.control= 28062 Channel= 38283 EntryStatus= valid
----------------------------------------------------------
FullStatus avail FullAction lock
Captured packets 251 Capture slice 1518
Download size 100 Download offset 0
Max Octet Requested 50000 Max Octet Granted 50000
Start time 1 days 0 hours 51 minutes 15 seconds
Owner monitor
captureEntry= 1 Buff.control= 28062
--------------------------------------------
Pkt ID 9 Pkt time 1 days 0 hours 51 minutes 15 seconds
Pkt Length 93 Pkt status 0
Data:
00 00 5e 00 01 01 00 01 f4 00 7d ce 08 00 45 00
00 4b b4 b9 00 00 40 11 32 5c 0a 15 43 05 86 8d
bf e5 00 a1 0e 2b 00 37 cf ca 30 2d 02 01 00 04
06 70 75 62 6c 69 63 a2 20 02 02 0c 92 02 01 00
02 01 00 30 14 30 12 06 0d 2b 06 01 02 01 10 07
01 01 0b 81 fd 1c 02 01 01 00 11 0b 00
set rmon capture
UsethiscommandtoconfigureanRMONcaptureentry.
Syntax
set rmon capture index {channel [action {lock}] [slice slice] [loadsize loadsize]
[offset offset] [asksize asksize] [owner owner]}
Parameters
index (Optional)Displaysthespecifiedbuffercontrolentryandallcaptured
packetsassociatedwiththatentry.
nodata (Optional)Displaysonlythebuffercontrolentryspecifiedbyindex.
index Specifiesabuffercontrolentry.
channel Specifiesthechanneltowhichthiscaptureentrywillbeapplied.
