Examples

This example displays the information from all of the neighbors on the

switch:

awplus# show lldp neighbors

This example displays the information from all of the neighbors that are

connected to ports 1 and 4:

awplus# show lldp neighbors interface port1.0.1,port1.0.4

Manufacturer Name The name of the company that

manufactured the device.

Model Name The model name.

Asset ID The asset ID number.

Table 106. SHOW LLDP NEIGHBORS DETAIL Command (Continued)

Parameter Description

Default Chapter5
