Port Settings

The following table lists the port configuration default settings.

Port Configuration Setting Default

Status Enabled

10/100/1000Base-T Speed Auto-Negotiation

Duplex Mode Auto-Negotiation

MDI/MDI-X Auto-MDI/MDIX

Threshold Limits for Ingress Packets Disabled

Broadcast, Multicast, or Unknown Unicast

Packet Filtering (Storm-control)

33,554,431 packets per

second

Override Priority No override

Head of Line Blocking Threshold 682 cells

Backpressure Disabled

Backpressure Threshold 7,935 cells

Flow Control - Send Disabled

Flow Control - Receive Disabled

Flow Control Threshold 7,935 cells

Maximum Packet Size

9198 bytes

1. Not adjustable.
