Chapter 52: GARP VLAN Registration Protocol Commands

836

NO GVRP TIMER LEAVEALL

Syntax

no gvrp timer leaveall

Parameters

None

Mode

Global Configuration mode

Description

Use this command to disable the GARP Leave All timer and return the

GVRP Leave All timer to its default value.

Note

The settings for this timer must be the same on all GVRP-active

network devices.

Example

This command sets the Leave All timer to 10 seconds:

awplus> enable

awplus# configure terminal

awplus(config)# no gvrp timer leaveall

Default Chapter5
