Chapter 61: MAC Address-based Port Security Commands

930

Figure 159. Example of SHOW PORT-SECURITY INTRUSION

INTERFACE Command

Port Security Intrusion List

Port Security Intrusion List (Last 10 Intrusions)

--------------------------------------------------------

Interface: Port 1.0.5 - 132 intrusion(s) detected

000:0900:127E 000:0900:127F 000:0900:027D

000:0900:027E 000:0900:027F 000:0900:1279

000:0900:127A 000:0900:127B 000:0900:127C

000:0900:127D
