Chapter 8: Basic Switch Management Commands

162

SHOW SYSTEM SERIALNUMBER

Syntax

show system serialnumber

Parameters

None

Mode

User Exec and Privileged Exec modes

Description

Use this command to display the serial number of the switch. Figure 39 is

an example of the output.

Figure 39. SHOW SYSTEM SERIALNUMBER Command

Example

This example displays the system’s serial number:

awplus# show system serialnumber

S05525A023600001

Default Chapter5
