Allied Telesis AT-9000 Series User Manual

Chapter 21: Enhanced Stacking
416
Configuring a Member Switch
This example shows you how to configure the switch as a member switch
of an enhanced stack. It configures the switch to be part of the same
enhanced stack with the same common VLAN as the command switch in
the previous example. Here are the specifications for the member switch:
 Common VLAN name: Tech_Support
 VID: 12
 Untagged VLAN ports: 4 and 5
1. This step creates the common VLAN.
2. Use the ESTACK RUN command in the Global Configuration mode to
activate enhanced stacking on the switch. It is not necessary to set the
switch to the member mode because that is the default setting.
awplus> enable
Enter the Privileged Executive
mode from the User Executive
mode.
awplus# configure terminal
Enter the Global Configuration
mode.
awplus(config)# vlan database
Enter the VLAN Interface mode.
awplus(config-vlan)# vlan 12 name Tech_Support
Create the Tech_Support VLAN
and assign it the VID 12.
awplus(config-vlan)# exit
Return to the Global Configuration
mode.
awplus(config)# interface port1.0.4-port1.0.5
Enter the Port Interface mode for
ports 4 to 5.
awplus(config-if)# switchport mode access
Designate the ports as untagged
ports.
awplus(config-if)# switchport access vlan 12
Add ports 4 and 5 to the
Tech_Support VLAN.
awplus(config-if)# end Return to the Privileged Exec
mode.
awplus# show vlan 12
Verify the new VLAN.
awplus# configure terminal
Enter the Global Configuration
mode.
