Chapter 62: 802.1x Port-based Network Access Control

946

Figure 162. Multi-Supplicant Mode

RADIUS

Authentication

Server

Port 1.0.6

Role: Authenticator

Operating Mode: Multi-Supplicant Mode

Ethernet Hub or

Non-802.1x-compliant

Switch

Authenticated

Supplicants
