Chapter 72: Address Resolution Protocol (ARP) Commands
1196
SHOW ARP
Syntax
show arp
Parameters
None
Modes
User Exec mode and Privileged Exec mode
Description
Use this command to display the ARP entries in the ARP cache.
Figure 197 is an example of the information displayed by this command.
Figure 197. SHOW ARP Command
The columns of the ARP table are described in Table 113.
IP ARP
ARP Cache Timeout ......... 300 seconds
Total ARP Entries ......... 2
IP Address MAC Address Interface Port Type
-----------------------------------------------------------------
10.0.0.1 eccd.6d41.9e57 vlan1 port1.0.10 Dynamic
10.0.0.150 000c.2957.96db vlan1 port1.0.10 Dynamic
10.0.0.75 0000.1a2a.f8bb vlan1 port1.0.1 Static
Table 113. SHOW ARP Command
Parameter Description
IP Address Indicates the IP address of the host.
MAC Address Indicates the MAC address of the host.
Interface Indicates the VLAN where the host is a
member.
Port Indicates the port number where the host
is connected.
