Allied Telesis AT-9000 Series User Manual

Chapter 58: VLAN Stacking
900 Section III: File System
Example of VLAN Stacking
Here is an example of how to configure VLAN stacking. In the example,
the customer’s network is connected to ports 5 and 6 on the switch, and
the provider’s network is connected to port 7. Thus, ports 5 and 6 will be
designated as customer ports and port 7 as the provider port. The service
provider wants to use VID 79 to identify the packets of this customer. So
the VID for the new VLAN has to be 79. The VLAN will be assigned the
name ABC_Inc. This example also changes the EtherType/Length value
to 0x8100.
The first step is to create the VLAN and assign it the VID 79:
awplus> enable
Enter the Privileged Executive
mode from the User Executive
mode.
awplus# configure terminal
Enter the Global Configuration
mode.
awplus(config)# vlan database
Enter the VLAN Configuration
mode.
awplus(config-vlan)# vlan 79 name ABC_Inc
Create the new VLAN with the
VLAN command.
awplus(config-vlan)# end
Return to the Global Configuration
mode.
awplus# show vlan
Use the SHOW VLAN command
to confirm the new VLAN.
VLAN ID Name Type State Member ports
(u)-Untagged, (t) Tagged
======= ======= ======= ======= ==========================
1 default STATIC ACTIVE port1.0.1(u) port1.0.2(u)
port1.0.3(u) port1.0.4(u)
port1.0.5(u) port1.0.6(u)
port1.0.7(u) port1.0.8(u)
port1.0.9(u) port1.0.10(u)
port1.0.11(u) port1.0.12(u)
port1.0.13(u) port1.0.14(u)
port1.0.15(u) port1.0.16(u)
port1.0.17(u) port1.0.18(u)
port1.0.19(u) port1.0.20(u)
port1.0.21(u) port1.0.22(u)
port1.0.23(u) port1.0.24(u)
port1.0.25(u) port1.0.26(u)
port1.0.27(u) port1.0.28(u)
79 ABC_Inc STATIC INACTIVE
