AT-9000 Switch Command Line User’s Guide

1405

SHOW IP HTTP

Syntax

show ip http

Parameters

None

Mode

Privileged Exec mode

Description

Use this command to display the status of the HTTP server on the switch.

Here is an example of the information.

Figure 223. SHOW IP HTTP Command

Example

This example display the status of the HTTP server on the switch:

awplus# show ip http

HTTP server enabled. Port: 80
