AT-9000 Switch Command Line User’s Guide

827

GVRP APPLICANT STATE NORMAL

Syntax

gvrp applicant state normal

Parameters

None

Mode

Global Configuration mode

Description

Use this command to disable GIP on the switch.

Note

Do not disable GIP if the switch is running GVRP. GIP is required for

proper GVRP operation.

Example

This example disables GIP on the switch:

awplus> enable

awplus# configure terminal

awplus(config)# gvrp applicant state normal
