Chapter 56: Private Port VLAN Commands

886

SHOW VLAN PRIVATE-VLAN

Syntax

show vlan private-vlan

Parameters

None

Mode

Privileged Exec mode

Description

Use this command to display the private-port VLANs on the switch. Here is

an example of the information.

Figure 150. SHOW VLAN PRIVATE-VLAN Command

Example

The following example displays the private-port VLANs on the switch:

awplus# show vlan private-vlan

Private VLANs:

VID Ports

-------------------------------------------------

12 4-8

28 17-24

Default Chapter5
