Chapter 48: MSTP Commands

752

SPANNING-TREE MST CONFIGURATION

Syntax

spanning-tree mst configuration

Parameters

None

Mode

Global Configuration mode

Description

Use this command to enter the MST mode.

Note

Only one spanning tree protocol, STP, RSTP, or MSTP, can be

active on the switch.

Confirmation Command

“SHOW SPANNING-TREE” on page 743

Example

This example enters the MST mode:

awplus> enable

awplus# configure terminal

awplus(config)# spanning-tree mstp mode

awplus(config)# spanning-tree mst configuration
