Chapter 77: Quality of Service (QOS) Commands

1310 Section X: Network Management

“SHOW MLS QOS MAPS COS-

QUEUE” on page 1326

Privileged Exec Displays the mappings of CoS priority

values to egress queues.

“SHOW MLS QOS MAPS DSCP-

QUEUE” on page 1327

Privileged Exec Displays the mappings of DSCP

priority values to port egress queues.

“WRR-QUEUE WEIGHT” on

page 1329

Port Interface Sets the QoS scheduling method to

weighted round robin.

Table 146. Quality of Service Commands

Command Mode Description

Default Chapter5
