Example

This example displays the configuration of the TACACS+ client on the

switch:

awplus# show tacacs

Server Status Indicates the status of the server host.

One of the following options is displayed:

– Alive: Indicates the server

is working correctly. The

sockets are successful.

– Dead: Indicates the server

has timed out or the

sockets are unsuccessful.

Table 157. SHOW TACACS Command (Continued)

Parameter Description

Default Chapter5
