G
F
W
D
F
F
W
D
[17] OEA OUTLET
PORT
[19] SLEEVE
BONDING
SPRING
[20] O-RING
[21] OEA EXHAUST
DUCT
[18] COUPLING
[20] O-RING
[1] AIR
SEPARATION
MODULE
[10] OVERTEMPERATURE
SHUTOFF VALVE
[11] CLAMP
[12] O-RING
2160851 S0000474425_V2
Air Separation Module Alternate Installation
Figure 402/47-11-01-990-802 (Sheet 7 of 11)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-11-01
Page 431
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 568, 569, 581, 583, 585, 588, 589 PRE SB
737-47-1012
