INBD
F
W
D
B
C
C
REAR SPAR
UPPER LIGHTNING SHIELD
WIRE BUNDLE
[3] CAP SCREW
[22] CLAMP
[23] SPACER
[20] COLLAR
[21] BOLT
(2 LOCATIONS)
FLAME
ARRESTOR
(REF)
VERTICAL
STIFFENER
[1] UPPER
LIGHTNING
SHIELD
UPPER LIGHTNING
SHIELD
2127610 S0000458936_V3
Upper Lightning Shield
Figure 401/47-21-08-990-801 (Sheet 4 of 4)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-21-08
Page 406
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 576, 577, 971; ILF 101, 151, 156-199, 301,
304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416,
424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518, 524, 531-533,
535-537, 541, 542, 552-556, 560-562, 571-575, 671, 672, 686, 703, 707-710,
803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970 POST SB 737-47-1003
