B C
D
MPD ITEM
53-230-00
STATION 727I (-900)
LEFT SIDE SHOWN
(RIGHT SIDE OPPOSITE)
STATION 727L (-900ER)
LEFT SIDE SHOWN
(RIGHT SIDE OPPOSITE)
STRINGER 18A
RIGHT SIDE SHOWN
(LEFT SIDE OPPOSITE)
STA
727I
CIRCUMFERENTAL
SKIN SPLICE
STA
727L
STA
727B
STA
727A
STRINGER
S-18A AFT
S-18A WEB
STATION 727
BULKHEAD
CIRCUMFERENTAL
SKIN SPLICE
FRAME
STRINGER
SPLICE
STRINGER
FRAME
STRINGER
STRINGER
SPLICE
2094379 S0000439211_V2
INTERNAL-GENERAL VISUAL: AFT CARGO COMPARTMENT
Figure 228/53-05-03-990-859 (Sheet 2 of 3)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 289
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
