F
W
D
C
AFT PASSENGER COMPARTMENT
(STA 807 TO 1016)
(LEFT SIDE IS SHOWN, RIGHT SIDE IS ALMOST THE SAME)
MPD ITEM
53-410-00
FORWARD SIDE OF
STA 1016 BULKHEAD
STR 10L
STR 14L
STR 4L
STA
807
STA
827
STA
887
STA
1016
STRINGER SPLICE
AND TENSION BOLTS
CIRCUMFERENTIAL
SKIN SPLICE
STRINGER
SPLICE
VERTICAL FIN
FRONT SPAR
FITTING
LONGITUDINAL
LAP SPLICES
2101274 S0000442503_V2
INTERNAL-GENERAL VISUAL: AFT PASSENGER COMPARTMENT, STA 663.75 TO STA 1016
Figure 254/53-05-03-990-863 (Sheet 3 of 4)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 298.64
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
