D
B
N
I
FWD
INBD
A-A
A
[2] SCUFF
PLATE
[7] SCUFF PLATE
[8] SCREWS
[2] SCUFF
PLATE
APPLY BMS 595
SEALANT
[11] NUT PLATE
(EXAMPLE)
[4] SCUFF PLATE
[6] FILLER SCUFF
PLATE
[7] SCUFF PLATE
APPLY BMS 595
SEALANT
SCUFF PLATES
(VIEW IN THE UP DIRECTION)
[4] SCUFF
PLATE
2470912 S0000578432_V1
Cargo Door Scuff Plate Installation
Figure 401/53-11-02-990-801 (Sheet 3 of 3)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-11-02
Page 414
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317, 318, 331-399, 401,
402, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 452, 491-495,
501-504, 507-510, 512-516, 518, 520, 523-528, 530-533, 535-537, 541, 542,
552-557, 559, 571-577, 686, 703, 707-710, 803-813, 821, 822, 831, 832, 836,
837, 841, 842, 851, 852, 854-858, 861-863, 871-874, 947 PRE SB
737-53-1276
