Boeing 737-600 - Page 1775

2
1
1
1
2
2
2
2
2
A-A
1
2
FITTING
BS 294.5 BULKHEAD
FITTING
CRACK LOCATION ON AIRPLANE WITH 5567 FLIGHT HOURS
CRACK LOCATION ON AIRPLANE WITH 5648 FLIGHT HOURS
(FITTING AFT FLANGE)
BBL
0
J72214 S0000174949_V2
Nose Gear Wheel Well
Figure 205/53-11-37-990-806 (Sheet 2 of 3)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-11-37
Page 232
D633A101-ILF Oct 15/2015
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
