HARDPOINT
FITTING
1.00 INCH
(25.4 mm)
(EXAMPLE)
SEAM
TAPE/PATCH
WATERSEAL
TAPE
SEALANTS
FLOOR
PANEL
LAVATORY AND GALLEY HARDPOINT FITTINGS
(EXAMPLE)
SEAT TRACK WITHOUT FILLER
(OPTIONAL METHOD 3)
SEAT TRACK WITH FILLER
(OPTIONAL METHOD 3)
FLOOR
PANEL
SEAT
TRACK
FLOOR
PANEL
SEAT
TRACK
CL
SEAT TRACK
WATERSEAL
TAPE
SEALANT
WATERSEAL
TAPE
SEALANT
SEAM TAPE
CL
SEAT TRACK
FILLER
2179827 S0000481179_V2
Water Seal Tape Application
Figure 801/53-21-00-990-802 (Sheet 3 of 7)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-21-00
Page 810
D633A101-ILF Oct 15/2015
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
