Boeing 737-600 - Page 1832

HARDPOINT
FITTING
LAVATORY AND GALLEY HARDPOINT FITTINGS
(OPTIONAL METHOD 2)
LAVATORY AND GALLEY HARDPOINT FITTINGS
(OPTIONAL METHOD 1)
SEALANT
SEALANT
FILLET
PATCH
WATERSEAL
TAPE
FLOOR
PANEL
HARDPOINT
FITTING
SEALANT
WATERSEAL
TAPE
PATCH
WATERSEAL
TAPE
FLOOR
PANEL
2180025 S0000481180_V2
Water Seal Tape Application
Figure 801/53-21-00-990-802 (Sheet 4 of 7)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-21-00
Page 811
D633A101-ILF Oct 15/2015
