[42] SHORT SHAFT
[36] CLAMP UP
BUSHING
[38] BEARING
[37] LONG
BUSHING
[31] STABILIZER
TRIM SHAFT
[40] SPROCKET
[35] BUSHING
[41] BEARING
[39] CHAIN
[33] CLAMP UP
BUSHING
LONG SHAFT
[34] BEARING
CONTROL STAND
F92843 S0006583062_V2
Control Shaft Components Installation
Figure 402/76-11-02-990-802-F00 (Sheet 1 of 2)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-02
Page 412
D633A101-ILF Jun 15/2019
