1
F
1
WIRES
(3 LOCATIONS)
[14] RETAINER
[15] WASHER
(3 LOCATIONS)
[7] TERMINAL STUD
(3 LOCATIONS)
[6] BUSHING
(3 LOCATIONS)
[8] SCREW
[9] WASHER
[16] SCREW
(3 LOCATIONS)
(EXAMPLE)
ELECTRICAL
CONNECTOR
[10] CURRENT
TRANSFORMER
[11] WASHER
(3 LOCATIONS)
[12] SCREW
(3 LOCATIONS)
EXTERNAL POWER CURRENT
TRANSFORMER, T378 HAS ONE WIRE
K21897 S0006566220_V2
Current Transformer Installation
Figure 401/24-21-71-990-801 (Sheet 6 of 6)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-21-71
Page 409
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 402,
405, 424, 425, 427-429, 451, 452, 491-504, 507-510, 512-516, 518-520, 523-528,
530-533, 535-537, 541, 542, 552-557, 559-564, 567-569, 571-577, 581, 583, 585,
588-590, 592-599, 601-603, 606, 607, 610-615, 620, 625-627, 671, 672, 686,
691-699, 703, 707-710, 803-813, 821, 822, 831-838, 841, 842, 851, 852, 854-858,
861-863, 871-874, 947, 948, 968-973, 980-999; ILF 401, 406, 409, 410, 412, 416
POST SB 737-24-1128
