IDLE
B-B
C-C
(VIEW IN THE FORWARD DIRECTION)
(EXAMPLE)
[30] LOWER
CENTER
SEAL
[29] FOIL MARKER
[39] SCREW
(2 LOCATIONS)
[28] SEAL RETAINER
RETAINER
HOUSING
SEAL
SPACER
G67641 S0006583081_V2
Control Stand Seal, Spacer, and Retainer Installation
Figure 402/76-11-03-990-802-F00 (Sheet 2 of 3)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-03
Page 411
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401,
402, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510,
512-516, 518-520, 523-528, 530-533, 535-537, 541, 542, 552-557, 559-564,
567-569, 571-577, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615,
620, 671, 672, 686, 691-699, 703, 707-710, 803-813, 821, 822, 831-834, 836, 837,
841, 842, 851, 852, 854-858, 861-863, 871-874, 947, 948, 968-973, 980-999
