Table 401/76-11-10-993-801-F00
CIRCUIT SETTINGS
Connector
(Switch) Connector Pin Numbers
Circuit Condition
(Switch Settings)
D11286P (S88) 11 and 12 More than 1 megohm
D11286P (S88) 11 and 13 Less than 1 ohm
D11286P (S1024) 15 and 5 More than 1 megohm
D11286P (S1024) 15 and 4 Less than 1 ohm
D11286P (S1026) 9 and 8 More than 1 megohm
D11286P (S1026) 9 and 7 Less than 1 ohm
D11288P (S89) 11 and 12 More than 1 megohm
D11288P (S89) 11 and 13 Less than 1 ohm
D11288P (S1025) 15 and 5 More than 1 megohm
D11288P (S1025) 15 and 4 Less than 1 ohm
D11288P (S595) 9 and 8 More than 1 megohm
D11288P (S595) 9 and 7 Less than 1 ohm
(c) Set the engine 1 start lever to the IDLE position.
(d) Do a check of the circuit values of the start brake assembly at the IDLE position.
1) Use a digital/analog multimeter, COM-1793 to measure the circuit values
(Table 402).
Table 402/76-11-10-993-802-F00
CIRCUIT SETTINGS
Connector
(Switch) Connector Pin Numbers
Circuit Condition
(Switch Settings)
D11286P (S88) 11 and 12 Less than 1 ohm
D11286P (S88) 11 and 13 More than 1 megohm
D11286P (S1024) 15 and 5 Less than 1 ohm
D11286P (S1024) 15 and 4 More than 1 megohm
D11286P (S1026) 9 and 8 Less than 1 ohm
D11286P (S1026) 9 and 7 More than 1 megohm
D11288P (S89) 11 and 12 Less than 1 ohm
D11288P (S89) 11 and 13 More than 1 megohm
D11288P (S1025) 15 and 5 Less than 1 ohm
D11288P (S1025) 15 and 4 More than 1 megohm
D11288P (S595) 9 and 8 Less than 1 ohm
D11288P (S595) 9 and 7 More than 1 megohm
(e) If you find that the measured circuits are as shown, do the electrical connector installation
steps.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-10
Page 413
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401,
402, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510,
512-516, 518-520, 523-528, 530-533, 535-537, 541, 542, 552-557, 559-564,
567-569, 571-577, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615,
620, 671, 672, 686, 691-699, 703, 707-710, 803-813, 821, 822, 831-834, 836, 837,
841, 842, 851, 852, 854-858, 861-863, 871-874, 947, 948, 968-973, 980-999
