Boeing 737-600 - Page 2295

A
B
A
F
W
D
D
C
F
W
D
B
[9] LOWER PNEUMATIC
STARTER DUCT
[3] UPPER PNEUMATIC
STARTER DUCT
[2] COUPLING
[2] COUPLING
[1] SEAL RING
[1] SEAL RING
[10] START VALVE
[4] ELECTRICAL
CONNECTOR
[5] NUT
[7] WASHER
[6] BONDING
JUMPER
[8] BOLT
F54759 S0006583783_V3
Start Valve Installation
Figure 401/80-11-03-990-801-F00 (Sheet 1 of 2)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
80-11-03
Page 403
D633A101-ILF Jun 15/2016
