C
FWD
D
SEAL INSTALLATION
(EXAMPLE)
[2] COUPLING
[3] UPPER PNEUMATIC
STARTER DUCT
[1] SEAL RING
[10] START VALVE
F55057 S0006583784_V2
Start Valve Installation
Figure 401/80-11-03-990-801-F00 (Sheet 2 of 2)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
80-11-03
Page 404
D633A101-ILF Jun 15/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
