Boeing 737-600 - Page 257

F
W
D
C
ELECTRICAL
CONNECTOR
SEAL
[2] BOLT
(6 LOCATIONS)
[3] WASHER
(6 LOCATIONS)
SKID PLATE
BATTERY
CONNECTOR
[1] BATTERY
BATTERY
F99258 S0006566282_V2
Battery Installation
Figure 401/24-31-11-990-801-001 (Sheet 4 of 5)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-11
Config 1
Page 406
D633A101-ILF Oct 15/2015
