D
F
W
D
EXTERNAL POWER RECEPTACLE
[15] SCREW
[16] WASHER
(4 LOCATIONS)
[17] NUT
(4 LOCATIONS)
[18] SHIELD
2068937 S0000429996_V2
External Power Receptacle Installation
Figure 401/24-41-11-990-804 (Sheet 3 of 4)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-41-11
Config 1
Page 406
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 588-590, 592, 980-999 PRE SB 737-24-1203
