NOMINAL OPERATING
TEMPERATURE 110 ±0.5˚ F
290
310
330
350
370
380
390
360
340
320
280
80 1601401201006040
300
MAX RESISTANCE
MIN RESISTANCE
AMBIENT TEMPERATURE, ˚ F
RESISTANCE, OHMS
2433813 S0000563187_V1
Window Heat Control Sensor Resistance
Figure 503/30-41-21-990-804
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
30-41-21
Page 511
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
