Chapter 30 Protocol-Independent Configuration DGS-3610 Series Configuration Guide

30-10

DGS-3610(config-if)# ip address 200.168.23.2 255.255.255.0

#Configure OSPF and set the redistribution route type

DGS-3610(config)# router ospf

DGS-3610(config-router)# redistribute rip metric 100 metric-type 1 subnets

DGS-3610(config-router)# network 192.168.12.0 0.0.0.255 area 0

#Configure the RIP and use the distribute list to filter the redistributed routes

DGS-3610(config)# router rip

DGS-3610(config-router)# redistribute ospf metric 2

DGS-3610(config-router)# network 200.168.23.0

DGS-3610(config-router)# distribute-list 10 out ospf

DGS-3610(config-router)# no auto-summary

#Define an access list

DGS-3610(config)# access-list 10 per

mit 192.168.10.0

Configuration of router C:

DGS-3610(config)# interface gigabitEthernet 0/0

DGS-3610(config-if)# ip address 200.168.30.1 255.255.255.0

DGS-3610(config)# interface gigabitEthernet 0/1

DGS-3610(config-if)# ip address 200.168.3.1 255.255.255.0

DGS-3610(config)# interface Serial 1/0

DGS-3610(config-if)# ip address 200.168.23.3 255.255.255.0

DGS-3610(config)# router rip

DGS-3610(config-router)# network 200.168.23.0

DGS-3610(config-router)# network 200.168.3.0

DGS-3610(config-router)# network 200.168.30.0

OSPF routes found by router A:

O E1 200.168.30.0/24 [110/101] via 192.168.12.5, 00:04:07, FastEthernet0/1

O E1 200.168.3.0/24 [110/101] via 192.168.12.5, 00:04:07, FastEthernet0/1

RIP routes found by Router C:

R 192.168.10.0/24 [120/2] via 200.168.23.2, 00:00:00, Serial1/0

30.2.3.3 Example of Configuring the Route Map

The route map can be configured very flexibly to be used on the route redistribution and

policy-based routing. No matter how the route map is used, the configuration principle is the

same, except that different command sets are used. Even if it is used on the route

redistribution, different routing protocols can use different commands with the route map.

In the following example, the OSPF routing protocol redistributes only the RIP routes whose

hops are 4. In the OSPF routing area, the type of the routes is external route type-1, the

initial metric is 40, and the route tag is 40.
