User Defined Tone SET - #UDTSET command
#UDTSET – User Defined Tone SET
<tone>
,<F1>,<A1>
Set command sets frequency and amplitude composition for a User Defined Tone.
Parameters:
<tone> - tone index (G,H,I,J,K,L)
<Fi> - frequency in Hz; range is (300,3000) in step of 1 Hz
<Ai> - amplitude in dB; range is (10,100) in step of 1 dB
Note: Ai = 100 is equal to the max value of the single tone. Lower values attenuate
output to the difference between 100 and the selected amplitude (ex: Ai = 80 is
equal to 100-80 = -20dB).
Note: issuing AT&F1 or AT&Z has the effect to set the parameters with the last
saved in NVM values
Note: Ai = 0 and Fi = 0 are only values for uninitialized parameters and can’t be
issued by AT command. Every time the set command is issued, the unspecified
parameters are automatically reset to zero.
(Ai,Fi) issuing needs also (Aj,Fj) with j<i.
Read command returns the current settings for the tones:
#UDTSET: G,
<F1>,
<A1>,<F
2>,<A2>,
<F3>,
<A3>
#UDTSET: H
, <F1>,
<A1>,<F
2>,<A2>,
<F3>,
<A3>
#UDTSET: I
, <F
1>,<A1>,<F
2>,<A2>,<F
3>,<A3
>
#UDTSET: J
, <F1
>,<A1>,<F
2>,<A2
>,<F3
>,<A3>
#UDTSET: K
, <F1>,
<A1>,<F
2>,<A2>,
<F3>,
<A3>
#UDTSET: L,
<F1>,
<A1>,<F
2>,<A2>,
<F3>,
<A3>
Test command returns the supported range of values for <tone>, <Fi> and <Ai>
parameters.
